Product features

  • Input Voltage: 12V-48V DC, Internal Integration of 12V and 5V Regulator
  • Output Current: 0.2-5A.
  • Average current control, 2 Phase sinusoidal current drive output
  • Optically isolated signal input / output - overvoltage, undervoltage, overcurrent, and white short-circuit protection
  • Fit For Nema 17 / Nema 23 / Nema 24 / Nema 34 Stepper Motor

Product description

►Product Specifications:

- Automatic idle-current reduction.
- Supply voltage up to 48V DC
- Output current up to 5.0A.
- Suitable for 2-Phase and 4-Phase motors.
- High speed optoelectronic isolation signal input.
- Single-chip PWM bipolar sinusoidal chopper ensures low vibration and high efficiency.
- 1, 2, 4 (New Mode), 8, 16 adjustable microstep control, motors run more precisely and smoothly.
- Equipped with the 3rd generation of breakout board, display panel and control pad to control the motor manually.
- Overload, overcurrent, overheat, overvoltage and undervoltage protection to avoid damaging your computer and devices.
- Cooling Aluminium Box Design for Cooling, and protect the driver board from being damaged by dirt, dust or other liquids.
- The TB1H is a high performance microstepping driver based on the latest original for TOSHIBA high-efficiency TB6600HG for IC. The TB6600HG adopts single-chip PWM bipolar sinusoidal chopper to ensure the low vibration and high efficiency.
- Moreover, the brand new design with BiCD0.13 (50V) process technology on the chipset also ensures maximum 5.0A output current and 50V output withstand voltage.
- Consequently, as long as the current range of the stepper motor is within 0.2-5 amps, all the 2 Phase or 4 Phase of Nema17, Nema23, Nema24 and Nema34 stepper motors will work perfectly with this new-type TB6600HG Stepper Driver


Package include:
►1 x HY-DIV268N-5A TB6600 Stepper Motor Driver Controller.
